AimSHOT
AIMS MTML-140 PR M-LOK QR LOCK ADAPT PIC RL 140M
- SKU:
- MTML140
- UPC:
- 669256713708
- MPN:
- MTML140
Description
When you need a Picatinny rail on a handguard that only has M‑LOK slots, this adapter drops in like a puzzle piece. The 140 mm length gives you a full‑size rail without extending far beyond the handguard, so your setup stays compact and maneuverable.
The integrated locking mechanism uses two large side buttons—press both to lock, press both again to release. That means you can swap out fore‑grips, lights or optics in seconds, even in the field, without reaching for a screwdriver. The newer, larger buttons make the action smooth and reliable.
Built from black anodized 6061‑T6 aluminum, the unit resists the harsh conditions of the range or the back‑country. It’s engineered for metal M‑LOK sections that are 2–3 mm thick; if your rail falls outside that range the fit may be compromised, so double‑check your handguard before purchase.
Key features
- 140 mm (≈5½ in) Picatinny rail – Fourteen MIL‑STD‑1913 slots give you a full‑length rail for optics, lights, lasers or fore‑grips, matching the standard rail spacing used on most accessories.
- Tool‑free two‑button release – Press the side buttons to lock the adapter onto the M‑LOK rail, then press both again to release it—no wrenches or screwdrivers needed for rapid changes on the range.
- Black anodized 6061‑T6 aluminum housing – The aircraft‑grade alloy resists corrosion and wear, while the anodized finish reduces glare and blends with most handguards.
- Fits metal M‑LOK sections 2–3 mm thick – Designed for the standard M‑LOK rail thickness; thinner or thicker rails may not seat properly, ensuring a solid connection on approved handguards.
- Lightweight construction (0.235 kg) – At under a quarter‑kilogram the adapter adds minimal front‑end weight, preserving the balance of your rifle.
- Low‑profile design – The rail sits close to the handguard, keeping the overall profile slim and preventing snagging on gear or foliage.
Specifications
| Brand | AimShot |
| Product name | MTML140 Quick Release M‑LOK to Picatinny Adapter |
| Model / MPN | MTML140 |
| UPC | 669256713708 |
| Handguard length (adapter) | 5.512 in |
| Weight | 0.2350 kg |
| Material | Black anodized 6061‑T6 aluminum |
| Rail / Attachment Type | Picatinny (MIL‑STD‑1913) |
| Picatinny slots | 14 |
| Compatible M‑LOK rail thickness | 2–3 mm (0.08–0.11 in) |
| Tool‑free quick release | Yes |
| Color | Black |
What’s included
- 1 × AimShot MTML140 Quick Release M‑LOK to Picatinny Adapter
Good to know
- Designed for metal M‑LOK sections only; it will not fit polymer or composite M‑LOK rails.
- The adapter must be installed on a rail that is between 2 mm and 3 mm thick; outside that range may result in a loose fit.
- Because the rail is low‑profile, it works well with most fore‑grips and accessories without adding excessive bulk.
Additional Information
Brand: |
Aimshot |
Handguard Length: |
5.512 in |
Model: |
MTML140 |
Product Weight: |
0.2350 kg |
Rail / Attachment Type: |
Picatinny (MIL-STD-1913) |
GTIN / UPC: |
669256713708 |
Package Quantity: |
1 |
Packaging Type: |
EA |
