Description
The Fast Mini FML19 squeezes a full‑size thermal imaging system into a pistol‑sized package. Its 384×288 sensor paired with a 19 mm F1.2 lens gives you a bright, high‑resolution view that stays clear from 700 yd out to the claimed 1,100 yd detection range. The 1.4‑inch display runs at 60 Hz, so moving heat signatures stay crisp and you can even watch a bullet’s impact glow in real time.
Mounting is straightforward: the unit ships with a standard RMR adapter that fits most pistol slides, and optional adapters let you bolt it to DPP, MOS or even a Picatinny rail for rifle use. The IP67‑rated aluminum housing survives rain, dust and up to 1200 g of recoil, making it rugged enough for daily carry or duty duty. Power comes from two rechargeable CR2 cells, giving roughly five hours of operation before you need to plug in the included USB‑C charger.
Key features
- 384×288 thermal sensor – Delivers high‑resolution imagery with a NETD ≤ 20 mK, letting you see heat signatures out to the manufacturer‑rated 1,100 yd.
- 19 mm F1.2 objective lens – Provides a bright, clear picture even in low‑light conditions, essential for quick target acquisition.
- 60 Hz refresh rate – Real‑time video eliminates motion blur, so moving subjects stay sharp and you can track breath or muzzle blast.
- IP67 waterproof, 1200 g recoil rated – Designed to survive rain, dust and the kick of pistols or AR platforms without loss of performance.
- Standard RMR footprint – Drops onto most RMR‑compatible pistol slides; adapters also cover DPP, MOS and other common pistol mounts.
- Rechargeable CR2 battery (5 hr runtime) – Two 3.7 V CR2 cells power the sight for up to five hours; recharge via the included USB‑C charger.
Specifications
| Brand | INFITAC |
| Product name | Fast Mini FML19 Thermal Sight |
| Model / MPN | FML19 |
| UPC | 850067573241 |
| Sensor resolution | 384×288 |
| Sensor NETD | ≤ 20 mK |
| Lens focal length | 19 mm |
| Lens aperture | F1.2 |
| Display size | 1.4 inches |
| Display resolution | 360×300 |
| Refresh rate | 60 Hz |
| Weight | 4 oz |
| Waterproof rating | IP67 |
| Recoil rating | 1200 g |
| Footprint | Standard RMR pistol adapter (optional DPP, MOS, Picatinny) |
| Battery type | Rechargeable 3.7 V CR2 (2 pcs) |
| Battery runtime | ≈ 5 hours |
| Warranty | Standard INFITAC warranty |
What’s included
- 1 × INFITAC Fast Mini FML19 Thermal Sight
- Standard RMR pistol adapter
- PA01 RMSC pistol adapter
- PA02 DPP pistol adapter
- PA03 Glock MOS pistol adapter
- PM01 Picatinny rail mount
- PM02 30 mm ring mount
- PM03 45° offset mount
- 2 × rechargeable CR2 batteries
- CR2 battery charger (USB‑C)
- Lens cleaning cloth
- User manual
- Warranty card
Good to know
- The RMR adapter fits most pistols with a pre‑cut RMR base; verify your slide’s footprint before purchase.
- Optional adapters allow mounting on rifles via Picatinny or 30 mm rings, expanding the sight’s platform versatility.
- Recharge the CR2 cells with the included USB‑C charger; spare batteries are sold separately.
- The unit is rated for up to 1200 g of recoil, making it suitable for both pistols and AR‑style platforms.
Additional Information
Adjustment Increment: |
1 moa |
Brand: |
Infitac |
Eye Relief: |
36 mm |
Field of View: |
10.2 ft@100yd |
Maximum Magnification: |
1 |
Minimum Magnification: |
1 |
Model: |
FML19 |
Objective: |
19 mm |
Optic Coating: |
Fully Coated |
Parallax Adjustment: |
Fixed (None) |
Reticle Focal Plane: |
Second Focal Plane (SFP) |
Tube Diameter: |
19 mm |
GTIN / UPC: |
850067573241 |
Optics Type: |
Red Dot / Reflex |
Battery Type: |
CR2 |
Finish: |
Black |
Reticle Type: |
Red Dot |
Waterproof: |
True |
Color: |
Black |
Package Quantity: |
1 |
Packaging Type: |
EA |
