PARD OC650/LRF Ocelot 640 LRF Thermal Black 2.5x50mm Multiple Reticle, 2x/4x/6x Zoom 640x512, 50 Hz Resolution
- SKU:
- OC650/LRF
- UPC:
- 850050408352
- MPN:
- OC650/LRF
- Width:
- 9.60 (in)
- Height:
- 4.00 (in)
- Depth:
- 23.70 (in)
Description
The Ocelot 640 LRF pairs a 50 mm objective with a 2.2× base magnification and up to 2‑8× digital zoom, giving you a flexible field of view that stays clear from 5 m to 5 km. The 800×800 IPS screen mirrors the 640×512 thermal sensor, so the picture you see is exactly what the sensor records, and the 50 Hz refresh rate keeps moving targets from blurring into the background.
A built‑in laser rangefinder reaches out to 1000 m, letting you lock in distance without ever taking your eye off the sight picture. The scope’s 100 mm eye‑relief and waterproof sealing make it comfortable and reliable in harsh field conditions, while the aircraft‑grade aluminum housing—just 16 oz—keeps the overall balance of your rifle intact.
Mounted on a cantilever Picatinny bracket, the Ocelot 640 LRF slides onto any standard rail. It’s ready for tactical, hunting, or surveillance use right out of the box, delivering the thermal clarity and range‑finding precision you need for decisive shots.
Key features
- 2.2× Base Magnification – Provides a low‑power view that lets you acquire targets quickly before dialing in digital zoom.
- 2‑8× Digital Zoom – Extends the field of view up to 2.5× overall magnification for precise aiming at longer ranges.
- 800×800 IPS Display – True‑round display delivers a crisp picture that matches the thermal sensor resolution for easy target identification.
- 640×512 VOx Sensor, 50 Hz Refresh – High‑resolution sensor with fast refresh captures subtle temperature differences, even in low‑contrast environments.
- Integrated Laser Rangefinder (≤1000 m) – Built‑in LRF lets you measure distance without removing the scope, streamlining long‑range engagements.
- Aircraft‑Grade Aluminum, 16 oz (455 g) – Lightweight yet durable construction keeps the scope balanced on the rifle and survives recoil up to 6000 J.
- 100 mm Eye Relief, Waterproof – Generous eye relief ensures comfort on recoil; sealed construction lets you shoot in rain or dust.
- Multi‑Coated Black Finish – Reduces glare and protects the optics from wear and the elements.
Specifications
| Brand | OPTIMAX TECHNOLOGY LLC |
| Product name | PARD Ocelot 640 LRF Thermal Scope |
| Model / MPN | OC650/LRF |
| UPC | 850050408352 |
| Objective lens | 50 mm |
| Base magnification | 2.2× |
| Digital zoom range | 2‑8× (overall up to 2.5×) |
| Display resolution | 800×800 IPS |
| Thermal sensor resolution | 640×512 |
| Refresh rate | 50 Hz |
| NETD | ≤20 mK |
| Field of view | 7.0° × 7.0° (≈14° diagonal) |
| Eye relief | 100 mm |
| Battery life | up to 5 hrs |
| Battery type | Other |
| Weight | 16 oz (455 g) |
| Dimensions (L×W×H) | 182 mm × 68 mm × 79 mm |
| Finish | Black, Multi‑Coated |
| Laser rangefinder range | ≤1000 m |
| Waterproof | True |
| Reticle type | Multiple, Second Focal Plane (SFP) |
What’s included
- 1 × PARD Ocelot 640 LRF Thermal Scope
- Cantilever Picatinny mounting bracket
- Owner’s manual
Good to know
- Fits any standard Picatinny rail; ensure the bracket is securely torqued before shooting.
- Uses a proprietary battery; verify you have the correct type and keep spares for extended outings.
- Laser rangefinder is effective up to 1000 m; beyond that distance the scope still provides thermal imaging but without range data.
- Water‑sealed construction allows use in rain or dusty environments, but wipe the exterior after exposure to salt water.
Additional Information
Field of View: |
19.8-14.0 Degrees |
Objective: |
50 mm |
Battery Life: |
5 hrs |
Adjustment Increment: |
0.1 mrad |
Brand: |
Optimax Technology |
Eye Relief: |
100 mm |
Maximum Magnification: |
2.5 |
Minimum Magnification: |
2.5 |
Model: |
Ocelot |
Optic Coating: |
Multi-Coated |
Parallax Adjustment: |
Fixed (None) |
Reticle Focal Plane: |
Second Focal Plane (SFP) |
Series: |
640 LRF |
GTIN / UPC: |
850050408352 |
Optics Type: |
Night Vision / Thermal |
Battery Type: |
Other |
Finish: |
Black |
Reticle Type: |
Other |
Waterproof: |
True |
Color: |
Black |
Package Quantity: |
1 |
Packaging Type: |
EA |
