Description
Warne’s Maxima Horizontal Quick‑Detach rings solve the annoying “scope‑to‑rail” dance. The high‑profile 34mm rings give you the clearance you need for larger objectives while the square recoil keys lock the ring firmly to the base, so the optic stays put even when you’re firing hard‑recoiling rifles. The sintered‑steel body is CNC‑machined for a tight, consistent clamp that won’t flex under stress.
The indexable Quick‑Detach lever is the real time‑saver: pull the lever, the optic drops off in a split‑second, and when you snap it back the zero stays where you left it. Warne backs that claim with a Return‑to‑Zero Guarantee, and the STANAG‑4694 interface adds a standardized, rigid mounting surface that many modern rifles use. Four Torx T‑15 cap screws let you torque the rings to the manufacturer‑recommended 18 in‑lb, ensuring repeatable, secure installation every time.
Key features
- High‑profile 34mm rings – The "high" height clears larger scopes and provides ample clearance for eye relief adjustments.
- Matte‑black finish – A non‑reflective coating reduces glare and blends with most tactical setups.
- Sintered steel construction – CNC‑machined from proprietary sintered steel for superior strength and consistent clamping under recoil.
- Four‑screw Torx caps – Securely fastens the rings with 4 × T‑15 cap screws, allowing precise torque (max 18 in‑lb) for repeatable mounting.
- Square, permanent recoil keys – Ensures positive engagement of the ring to the base, preventing slippage during heavy shooting.
- STANAG 4694 interface – Provides a standardized mounting surface that improves return‑to‑zero performance and overall rigidity.
- Quick‑Detach lever system – Tool‑free removal and re‑installation of the optic while maintaining zero, backed by Warne’s Return‑to‑Zero Guarantee.
- Fits Weaver, Picatinny & Maxima bases – Versatile compatibility lets you mount the rings on most common rail systems without adapters.
Specifications
| Brand | Warne |
| Product name | Warne 522LM Maxima Horizontal Quick Detach Scope Rings |
| Model / MPN | 522LM |
| UPC | 656813115099 |
| Scope tube diameter | 34 mm |
| Maximum objective size | 56 mm |
| Ring height | High |
| Finish | Matte Black |
| Material | Sintered Steel |
| Weight (pair) | 8.2 oz |
| Mounting interface | STANAG 4694 |
| Cap screw type | 4 × Torx T‑15 |
| Recoil key type | Square, permanently installed |
| Compatibility | Weaver, Picatinny, Maxima Horizontal bases |
| Quick‑Detach system | Indexable lever, tool‑free removal |
| Torque specification | Maximum 18 in‑lb (dry threads) |
What’s included
- 1 × pair of Warne 522LM 34 mm Quick Detach scope rings (high profile, matte black)
Good to know
- Designed for 34 mm tube scopes with objectives up to 56 mm; ensure the scope’s objective does not contact the barrel when mounted.
- Compatible with both Weaver‑style Maxima bases and Picatinny rails – no adapters required.
- Torque the cap screws to a maximum of 18 in‑lb; over‑tightening can strip threads or damage the recoil key.
- All rings are CNC‑machined in the USA from proprietary sintered steel for maximum durability.
Additional Information
Brand: |
Warne |
Material: |
Metal |
Model: |
522LM |
Tube Diameter: |
34 mm |
GTIN / UPC: |
656813115099 |
Rail / Attachment Type: |
Picatinny (MIL-STD-1913) |
Mount Type: |
Quick Disconnect |
Color: |
Black |
Finish: |
Matte |
Package Quantity: |
1 |
Packaging Type: |
EA |
