ATN

ATN TIMNBLT619G6 BLAZETREK 619 1.5-12X

(No reviews yet) Write a Review
SKU:
TIMNBLT619G6
UPC:
658175473459
MPN:
TIMNBLT619G6
Width:
5.10 (in)
Height:
4.00 (in)
Depth:
7.20 (in)
$1,299.00

Description

The BlazeTrek 6 619 packs a 12 µm VOx uncooled focal‑plane array into a rugged 6.2 × 2.23 × 1.98‑inch housing. The 640×512 resolution and ≤18 mK NETD give you a thermal picture that stays crisp at the full 1,000 m detection range, while the 19 mm F/1.0 lens delivers a 1.5‑12× optical zoom that lets you hunt or scout from a distance without losing situational awareness.

Its OLED display (800×600) shows the image with high contrast, and the built‑in Wi‑Fi lets you stream live video to a phone or tablet via the ATN Connect app. Six built‑in color palettes (White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia) let you tailor the image to the environment, and hot‑point tracking keeps moving targets centered automatically.

Weighing only 320 g and sealed to IP67, the monocular survives rain, dust and sub‑zero temperatures. The internal rechargeable battery runs about 6.5 hours, and a USB‑C port lets you power the unit from an external source or download footage. With 32 GB of onboard storage, you can capture video and stills without needing extra media cards.

Key features

  • 640×512 VOx sensor – Delivers 327,680 pixels per frame, giving you a detailed thermal picture that keeps animal outlines recognizable at long range.
  • ≤18 mK NETD – Thermal sensitivity lets the device discern minute temperature differences, so targets stand out even in cluttered environments.
  • 1.5‑12× magnification – A 19 mm F/1.0 lens provides a versatile zoom range for close‑range scouting and 1000 m detection without sacrificing field of view.
  • 50 Hz refresh rate – Smooth motion tracking and reduced image lag, essential for moving game or tactical movement.
  • IP67 waterproof rating – Fully sealed against dust and water, the monocular operates from –30 °C to 55 °C, making it reliable in harsh weather.
  • 32 GB internal storage & video capture – Record video or stills on‑board; footage can be transferred via USB‑C or shared live through the ATN Connect app.
  • Battery life ~6.5 hrs – Internal rechargeable battery provides several hours of continuous operation; external power can be supplied via USB‑C.

Specifications

BrandATN
Product nameBlazeTrek 6 619 Thermal Monocular
Model / MPNTIMNBLT619G6
UPC658175473459
Detector type12 µm VOx Uncooled Focal Plane Array
Sensor resolution640×512
Refresh rate50 Hz
Thermal sensitivity (NETD)≤18 mK
Lens focal length19 mm
Lens apertureF/1.0
Magnification1.5‑12×
Field of view22.8° × 18.3°
Detection range1000 m
Display resolution800×600 OLED
Diopter adjustment-5 to +5 D
Color palettesWhite Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia
Video recordingYes
Image captureYes
Internal storage32 GB
Battery typeInternal rechargeable
Battery life~6.5 hrs
External power supportUSB‑C 5 VDC / 2 A
Waterproof ratingIP67
Operating temperature range-30 °C to 55 °C
Dimensions (L×W×H)6.20 in × 2.23 in × 1.98 in (158 mm × 57 mm × 50 mm)
Weight320 g (0.7 lb)

What’s included

  • 1 × ATN BlazeTrek 6 619 Thermal Monocular

Good to know

  • Battery life is approximately 6.5 hours; an external USB‑C power source can extend run time.
  • IP67 rating means the unit is dust‑tight and can be submerged in up to 1 m of water for short periods.
  • Works with the ATN Connect app for live streaming, media management and AI‑assisted help.
  • Detection range is rated to 1000 m (≈1093 yd) under optimal conditions.
  • Weight of 320 g makes the monocular easy to carry on a rifle or head‑mounted rig.
View AllClose

Additional Information

Brand:
ATN
Maximum Magnification:
12
Minimum Magnification:
1.5
Model:
TIMNBLT619G6
Objective:
19 mm
Parallax Adjustment:
Fixed (None)
GTIN / UPC:
658175473459
Optics Type:
Night Vision / Thermal
Battery Type:
Proprietary Rechargeable Pack
Finish:
Black
Package Quantity:
1
Packaging Type:
EA
Reticle Type:
Other
Waterproof:
True
