Description
The ThOR 5 XD’s Gen 5 thermal detector pushes detection out to 4 km at the 4‑40× setting, giving you a clear picture of heat signatures even in hot, humid environments. The 1280×1024 pixel array paired with 60 fps video ensures that moving targets stay sharp and easy to track, while the AI‑enhanced SharpIR™ processing cleans up low‑contrast scenes for reliable identification. A Smart Mil‑Dot reticle sits on top of the thermal image, letting you make quick range and hold‑over calculations without having to switch to a separate ballistic calculator. The scope mounts via industry‑standard 30 mm rings, so it bolts onto any rifle that accepts a Picatinny or NATO rail, and the black anodized housing stands up to the elements without adding glare. Built‑in recoil‑activated video records a ten‑second pre‑trigger buffer and a five‑second post‑trigger clip, so you can review the shot sequence or capture compelling footage for training or sharing. With its rugged construction and high‑resolution sensor, the ThOR 5 XD is a versatile thermal solution for hunters, tactical shooters, and anyone needing reliable long‑range thermal imaging.
Key features
- 4‑40× Magnification – Zoom from 4× to 40× lets you acquire targets at long range and then dial in for precise shot placement.
- 1280×1024 12 µm Sensor – High‑resolution detector captures fine thermal detail and runs at 60 fps for smooth tracking of moving game.
- Smart Mil‑Dot Reticle – Integrated Mil‑Dot pattern provides quick range estimation and hold‑over without swapping optics.
- Standard 30 mm Ring Mount – Fits any common rail or mount, so you can pair it with rifles, carbines or pistols that accept 30 mm rings.
- Recoil‑Activated Video Recording – Captures 10 seconds before and 5 seconds after a shot, useful for after‑action review or sharing footage.
- Black Anodized Finish – Durable, non‑reflective coating protects the scope from harsh field conditions and reduces glare.
Specifications
| Brand | ATN |
| Product name | ThOR 5 XD 4-40x Smart Mil‑Dot Thermal Rifle Scope |
| Model / MPN | TIWST51210A |
| UPC | 658175123514 |
| Sensor resolution | 1280×1024 |
| Pixel pitch | 12 µm |
| Frame rate | 60 fps |
| Magnification range | 4‑40× |
| Field of view | 8.8° × 6.6° |
| Mounting interface | Standard 30 mm rings |
| Reticle | Smart Mil‑Dot |
| Finish | Black anodized |
| Size (L×W×H) | 12.44" × 2.2" × 2.1" |
| Laser rangefinder | No |
| Video recording | Recoil‑activated, 10 s pre‑trigger, 5 s post‑trigger |
What’s included
- 1 × ATN ThOR 5 XD 4‑40× Thermal Rifle Scope
- Owner’s Manual
Good to know
- The scope uses a standard 30 mm ring, so verify your platform’s rail spacing before purchase.
- No built‑in laser rangefinder; pair with an external LRF if distance measurement is required.
- Black anodized finish may show minor wear over time, but it resists corrosion and reduces glare.
Additional Information
Battery Life: |
10 |
Brand: |
ATN |
Field of View: |
8.8 ft@100yd |
Maximum Magnification: |
40 |
Minimum Magnification: |
4 |
Model: |
Thor 5 XD |
Objective: |
50 mm |
Primary Application: |
Law Enforcement |
Series: |
Thor 5 |
Tube Diameter: |
30 mm |
GTIN / UPC: |
658175123514 |
Eye Relief: |
90 mm |
Optic Coating: |
Anti-Fog |
Overall Length: |
12.440 in |
Parallax Adjustment: |
Fixed (None) |
Reticle Focal Plane: |
Second Focal Plane (SFP) |
Optics Type: |
Night Vision / Thermal |
Battery Type: |
Other |
Finish: |
Anodized |
Reticle Type: |
Other |
Waterproof: |
True |
Color: |
Black Anodized |
Package Quantity: |
1 |
Packaging Type: |
EA |
